RealityCapture Selected Ortho Projection Report

Bericht über ausgewählte Orthoprojektion

Projekt: hammersmith

Sat, Jan 24, 2026 13:09:03

RealityCapture 1.5.1.118081 RC

Orthoprojektionsname Ortho projection 3
Komponentenname Component 0
Georeferenziert True
Verfügt über ein digitales Geländemodell True
Rendering method True ortho from a colored model
Breite [Pixel] 31794
Höhe [Pixel] 30705
Einheiten pro Spaltenpixel 0.013044
Einheiten pro Zeilenpixel 0.013045
Tiefe der Begrenzungsbox (Länge in der x-Richtung) 414.726112 m
Breite der Begrenzungsbox (Länge in der y-Richtung) 400.548724 m
Höhe der Begrenzungsbox (Länge in der z-Richtung) 38.350739 m
Schnittvolumen 1310276.24 m3
Füllvolumen 2677619.90 m3
Fläche 2D 103968.07 m2
Fläche 3D 206443.15 m2
Koordinatensystem epsg:4326 - GPS (WGS 84)
Orthoprojektionstyp Map (GPS)
Projektion Lat/long (Geodetic alias)
Zentrum der Begrenzungsbox in epsg:4326 - GPS (WGS 84) Koordinatensystem lat: 52° 7' 1.52398'' N
lon: 8° 41' 46.5325'' E
alt: 153.522535 m
Ecken in epsg:4326 - GPS (WGS 84) Koordinatensystem NW: lat: 52° 7' 8.00361'' N , lon: 8° 41' 35.6342'' E
NE: lat: 52° 7' 8.00333'' N , lon: 8° 41' 57.4308'' E
SE: lat: 52° 6' 55.0443'' N , lon: 8° 41' 57.4308'' E
SW: lat: 52° 6' 55.0446'' N , lon: 8° 41' 35.6342'' E
Nullmeridian greenwich
Einheiten Meter
Bild- und DOM-Rasterisierungszeit 00h:04m:00s
DGM Generierungszeit 00h:09m:39s
Gesamtdauer 00h:13m:42s
True Ortho-projection Digital Surface Model Digital Terrain Model
136.97 m
172.70 m
Abbildung 1: Vorschau der Bildebene der Orthoprojektion (links), DOM- und DGM-Höhenebene mit Maßstab (rechts)

Abbildung 2: Verteilung der Kontrollpunkte auf der Bildebene des Orthoprojektions

Figure 3: regions
